Scientists from UK & Japan Unravel Perovskite’s High Efficiency Enigma

Highlights :

  • Its heterogeneity of chemical elements causes defects in perovskite that reduce the photovoltaic performance of solar cells made from it.
  • Despite this, perovskite materials still show efficiency levels comparable to their silicon alternatives.
Scientists from UK & Japan Unravel Perovskite’s High Efficiency Enigma $12 Mn Investment Closed by Reliance & Others in California's Perovskite Solar Firm Caelux

In their breakthrough collaborative work, scientists from the Cavendish Laboratory, University of Cambridge, the Diamond Light Source synchrotron facility in Didcot, Oxfordshire, and the Okinawa Institute of Science and Technology in Japan have offered explanations for why perovskite materials are seemingly so tolerant of defects in their structure. Their findings have been published in Nature Nanotechnology.

The most commonly used material for producing solar panels is crystalline silicon, but to achieve efficient energy conversion requires an energy-intensive and time-consuming production process to create the highly ordered wafer structure required.

In the last decade, perovskite materials have emerged as promising alternatives, according to scientists.

The lead salts used to make them are much more abundant and cheaper to produce than crystalline silicon, and they can be prepared in a liquid ink that is simply printed to produce a film of the material. They also show great potential for other optoelectronic applications, such as energy efficient light emitting diodes (LEDs) and X-ray detectors.

The impressive performance of perovskites is surprising. The typical model for an excellent semiconductor is a very ordered structure, but the array of different chemical elements combined in perovskites creates a much ‘messier’ landscape.

This heterogeneity causes defects in the material that lead to nanoscale ‘traps’, which reduce the photovoltaic performance of the devices. But despite the presence of these defects, perovskite materials still show efficiency levels comparable to their silicon alternatives.

In fact, earlier research has shown the disordered structure can actually increase the performance of perovskite optoelectronics, and in their latest work, the scientists seek to explain why.

Combining a series of new microscopy techniques, the researchers present a complete picture of the nanoscale chemical, structural and optoelectronic landscape of these materials, that reveals the complex interactions between these competing factors and ultimately, shows which comes out on top.

“The idea is we do something called multimodal microscopy, which is a very fancy way of saying that we look at the same area of the sample with multiple different microscopes and basically try to correlate properties that we pull out of one with the properties we pull out of another one,” says PhD student Kyle Frohna, CEB. “These experiments are time consuming and resource intensive, but the rewards you get in terms of the information you can pull out are excellent.”

The findings will allow this project’s scientists and others in the field to further refine how perovskite solar cells are made in order to maximise efficiency.

“For a long time, people have thrown the term defect tolerance around, but this is the first time that anyone has properly visualised it to get a handle on what it actually means to be defect tolerant in these materials.

“Knowing that these two competing disorders are playing off each other, we can think about how we effectively modulate one to mitigate the effects of the other in the most beneficial way.”

“In terms of the novelty of the experimental approach, we have followed a correlative multimodal microscopy strategy, but not only that, each standalone technique is cutting edge by itself,” says Miguel Anaya, Royal Academy of Engineering Research Fellow at CEB.

“We have visualised and given reasons why we can call these materials defect tolerant. This methodology enables new routes to optimise them at the nanoscale to, ultimately, perform better for a targeted application. Now, we can look at other types of perovskites that are not only good for solar cells but also for LEDs or detectors and understand their working principles.

“Even more importantly, the set of acquisition tools that we have developed in this work can be extended to study any other optoelectronic material, something that may be of great interest to the broader materials science community.”

“Through these visualisations, we now much better understand the nanoscale landscape in these fascinating semiconductors – the good, the bad and the ugly,” says Sam Stranks, University Assistant Professor in Energy at CEB.

“These results explain how the empirical optimisation of these materials by the field has driven these mixed composition perovskites to such high performances. But it has also revealed blueprints for design of new semiconductors that may have similar attributes – where disorder can be exploited to tailor performance.”
